99.95% Pure W High-Density Tungsten Sphere
99.95% Pure W High-Density Tungsten Sphere
Pioneer New Material tungsten spheres are precision-engineered to deliver unmatched density (19.3 g/cm³) and dimensional stability. Manufactured from 99.95% pure tungsten through advanced powder metallurgy and CNC grinding processes, these spheres outperform steel, lead, and ceramic alternatives in extreme environments.
Key Advantages
✓ Extreme Density - 2.5× denser than steel, ideal for compact counterweights
✓ Thermal Stability - Maintains shape up to 2000°C in inert atmospheres
✓ Corrosion Resistance - Impervious to acids/alkalis (except HF/HNO₃ mix)
✓ Custom Configurations - Coatings (Au, TiN), laser marking, alloy blends
|
Parameter |
Specification |
|
Material |
99.95% W, WNiFe, WLa (Optional) |
|
Diameter Range |
Ø0.5mm - Ø100mm (±0.005mm tolerance) |
|
Density |
19.3 g/cm³ (Pure W) |
|
Surface Finish |
Grade 10-25 (Ra 0.025-0.4μm) |
|
Sphericity |
≤0.1μm (Grade 10 per ISO 3290) |
|
Magnetic Property |
Non-Magnetic (μ<1.001) |
Industrial Applications
Metrology & Calibration
• Master balls for CMM probe qualification
• Roundness test references (ISO 3290 Class 10)
Radiation Shielding
• Non-toxic alternative to lead in X-ray/CT equipment
• Nuclear reactor component testing
Aerospace & Defense
• Gyroscope balancing weights
• Kinetic energy research spheres
Scientific Research
• High-energy physics collision experiments
• Centrifuge calibration standards
